HOBBYWING SKYWALKER QUATTRO RC Model 25A x4 Brushless Speed Controller ESC SL012 New Arrival

Posted on April 26, 2013 by HobbyHot.com

HOBBYWING SKYWALKER QUATTRO RC Model 25A x4 Brushless Speed Controller ESC SL012 – New Arrival!

HOBBYWING SKYWALKER QUATTRO RC Model 25A x4 Brushless Speed Controller ESC SL012
Available at www.hobbyhot.com – Promising RC Model Shop Hong Kong,China
Check our cheap and high quality RC Model

Specification
Model: Skywalker Quattro 25Ax4-UBEC
Cont. Current: 20Ax4
Burst Current (>10s): 30Ax4
BEC Mode: Switch mode
BEC Output: 5V/3A
BEC Output Capability: 2S Lipo (5 Servos), 3S Lipo (5 Servos), 4S Lipo (4 Servos)
Battery Cell: Lipo 2-4S, NiMH 5 – 12 cells
Weight: 112g
Dimensions (L x W x H): 70 x 62 x 11mm

Features
4 speed controllers in 1 board, only 1 pair of battery wire is needed
Powerful switch mode built-in (the BEC voltage outputs from the S3 connector)
Multiple protection features: Low voltage cut-off protection / over-heat protection / throttle signal loss protection
The throttle range of each ESC can be calibrated to be suitable for different multi-rotor flying control systems / transmitters
Maximum speed: 210000 RPM (2 poles motor), 70000 RPM (6 poles motor), 35000 RPM (12 poles motor)

Posted in New Arrival Product | Tagged 25A, Brushless, Controller, ESC, HOBBYWING, Model, QUATTRO, RC, SKYWALKER, SL012, Speed, x4 | Leave a comment

HOBBYWING XERUN Blue V21 RC Brushless Motor 90A ESC Speed Controller SL209 New Arrival

Posted on April 26, 2013 by HobbyHot.com

HOBBYWING XERUN Blue V21 RC Brushless Motor 90A ESC Speed Controller SL209 – New Arrival!

HOBBYWING XERUN Blue V21 RC Brushless Motor 90A ESC Speed Controller SL209
Available at www.hobbyhot.com – Promising RC Model Shop Hong Kong,China
Check our cheap and high quality RC Model

Specification
Model: XERUN-90A-V2
Cont./Brust Current: 90A/520A
Resistance: 0.0005 ohm
Suitable Car: 1/10, 1/12 on-road & off road, 1/8, 1/10 scale rock crawler
Suitable Motor: Sensored and sensorless Brushless Motors
5-6 NIMH or 2 Lipo: >/=5.5T(on-road), >/=8.5T (off-road)
8-9 NIMH or 3 Lipo: >/=10.5T(on-road), >/=17.5T(off-road)
Battery: 4-9 cells NiMH or 2-3 cell s Li-Po
BEC Output: 5.75V@3A Built-in BEC
Dimension: 43mm(L) x 36mm(W) x 33mm(H)
Weight: 85g
Fan Working Voltage: 5V@0.16A , maximum 8V. (The fan gets the power supply directly from the battery)

Posted in New Arrival Product | Tagged 90A, Blue, Brushless, Controller, ESC, HOBBYWING, Motor, RC, SL209, Speed, V21, XERUN | Leave a comment

HOBBYWING XERUN Black V21 RC Brushless Motor 90A ESC Speed Controller SL210 New Arrival

Posted on April 26, 2013 by HobbyHot.com

HOBBYWING XERUN Black V21 RC Brushless Motor 90A ESC Speed Controller SL210 – New Arrival!

HOBBYWING XERUN Black V21 RC Brushless Motor 90A ESC Speed Controller SL210
Available at www.hobbyhot.com – Promising RC Model Shop Hong Kong,China
Check our cheap and high quality RC Model

Posted in New Arrival Product | Tagged 90A, Black, Brushless, Controller, ESC, HOBBYWING, Motor, RC, SL210, Speed, V21, XERUN | Leave a comment

HOBBYWING EZRUN 85T 4000KV 300W Sensored Brushless Motor Blue 90A ESC ME149 New Arrival

Posted on April 25, 2013 by HobbyHot.com

HOBBYWING EZRUN 85T 4000KV 300W Sensored Brushless Motor Blue 90A ESC ME149 – New Arrival!

HOBBYWING EZRUN 85T 4000KV 300W Sensored Brushless Motor Blue 90A ESC ME149
Available at www.hobbyhot.com – Promising RC Model Shop Hong Kong,China
Check our cheap and high quality RC Model

Motor Specification
Motor: 8.5T
KV/Power: 4000KV/300W
Gear Rate: 1/10 On road: 6.0-7.0, 1/10 Off road: 8.0-9.6
Suitable ESC: 120A/90A
Application: 1/10, 1/12 On-Road sportful racing, 1/10, 1/12 Off-road sportful racing

ESC Specification
Model: XERUN-90A-V2
Cont./Brust Current: 90A/520A
Resistance: 0.0005 ohm
Suitable Car: 1/10, 1/12 on-road & off road, 1/8, 1/10 scale rock crawler
Suitable Motor: Sensored and sensorless Brushless Motors
5-6 NIMH or 2 Lipo: >/=5.5T(on-road), >/=8.5T (off-road)
8-9 NIMH or 3 Lipo: >/=10.5T(on-road), >/=17.5T(off-road)
Battery: 4-9 cells NiMH or 2-3 cell s Li-Po
BEC Output: 5.75V@3A Built-in BEC
Dimension: 43mm(L) x 36mm(W) x 33mm(H)
Weight: 85g
Fan Working Voltage: 5V@0.16A , maximum 8V. (The fan gets the power supply directly from the battery)

ESC Features
Compatible with all sensorless brushless motors and most of sensored brushless motors such as LRP, SpeedPassion, Novak, etc
Seamlessly change to sensorless working mode when the sensor cable is broken
Excellent start-up, acceleration and linearity features
Built-in BEC has a powerful output to supply all the electronic equipment
Firmware can be updated through an USB adapter on the advanced LCD Program Box (Optional equipment)
User programmable. Easily programmed with the "SET" buttom the ESC and also compatible with the 3 digital LEDs Program Card and the advanced professional LCD Program Box
- 3 running modes (Forward mode, Forward/Reverse mode, Rock Crawler mode)
- 4 steps of maximum reverse force adjustment
- Proportional ABS brake function with 4 steps of maximum brake force adjustment , 8 steps of drag-brake force adjustment and 4 steps of initial brake force adjustment
- 9 start modes (Also called " Punch") from "very aggressive (level 9)"
- 8 steps of timing adjustment to suitable for all brushless motors
- Multiple protection features: Low voltage cut-off protection / Over-heat protection / Throttle signal loss protection / Motor blacked

Posted in New Arrival Product | Tagged , 300W, 4000KV, 85T, 90A, Blue, Brushless, ESC, EZRUN, HOBBYWING, ME149, Motor, Sensored | Leave a comment

HOBBYWING EZRUN 85T 4000KV 300W Sensored Brushless Motor Black 90A ESC ME150 New Arrival

Posted on April 25, 2013 by HobbyHot.com

HOBBYWING EZRUN 85T 4000KV 300W Sensored Brushless Motor Black 90A ESC ME150 – New Arrival!

HOBBYWING EZRUN 85T 4000KV 300W Sensored Brushless Motor Black 90A ESC ME150
Available at www.hobbyhot.com – Promising RC Model Shop Hong Kong,China
Check our cheap and high quality RC Model

ESC FeaturesCompatible with all sensorless brushless motors and most of sensored brushless motors such as LRP, SpeedPassion, Novak, etc
Seamlessly change to sensorless working mode when the sensor cable is broken
Excellent start-up, acceleration and linearity features
Built-in BEC has a powerful output to supply all the electronic equipment
Firmware can be updated through an USB adapter on the advanced LCD Program Box (Optional equipment)
User programmable. Easily programmed with the "SET" buttom the ESC and also compatible with the 3 digital LEDs Program Card and the advanced professional LCD Program Box
- 3 running modes (Forward mode, Forward/Reverse mode, Rock Crawler mode)
- 4 steps of maximum reverse force adjustment
- Proportional ABS brake function with 4 steps of maximum brake force adjustment , 8 steps of drag-brake force adjustment and 4 steps of initial brake force adjustment
- 9 start modes (Also called " Punch") from "very aggressive (level 9)"
- 8 steps of timing adjustment to suitable for all brushless motors
- Multiple protection features: Low voltage cut-off protection / Over-heat protection / Throttle signal loss protection / Motor blacked

Posted in New Arrival Product | Tagged , 300W, 4000KV, 85T, 90A, Black, Brushless, ESC, EZRUN, HOBBYWING, ME150, Motor, Sensored | Leave a comment

HOBBYWING EZRUN 105T 3300KV 250W Sensored Brushless Motor Blue 90A ESC ME154 New Arrival

Posted on April 25, 2013 by HobbyHot.com

HOBBYWING EZRUN 105T 3300KV 250W Sensored Brushless Motor Blue 90A ESC ME154 – New Arrival!

HOBBYWING EZRUN 105T 3300KV 250W Sensored Brushless Motor Blue 90A ESC ME154
Available at www.hobbyhot.com – Promising RC Model Shop Hong Kong,China
Check our cheap and high quality RC Model

Motor Specification
Motor: 10.5T
KV/Power: 3300KV/250W
Gear Rate: 1/10 On road: 5.0-6.0, 1/10 Off road: 7.5-8.5
Suitable ESC: 120A/90A
Application: 1/10, 1/12 On-Road sportful racing, 1/10, 1/12 Off-road sportful racing

ESC FeaturesCompatible with all sensorless brushless motors and most of sensored brushless motors such as LRP, SpeedPassion, Novak, etc
Seamlessly change to sensorless working mode when the sensor cable is broken
Excellent start-up, acceleration and linearity features
Built-in BEC has a powerful output to supply all the electronic equipment
Firmware can be updated through an USB adapter on the advanced LCD Program Box (Optional equipment)
User programmable. Easily programmed with the "SET" buttom the ESC and also compatible with the 3 digital LEDs Program Card and the advanced professional LCD Program Box
- 3 running modes (Forward mode, Forward/Reverse mode, Rock Crawler mode)
- 4 steps of maximum reverse force adjustment
- Proportional ABS brake function with 4 steps of maximum brake force adjustment , 8 steps of drag-brake force adjustment and 4 steps of initial brake force adjustment
- 9 start modes (Also called " Punch") from "very aggressive (level 9)"
- 8 steps of timing adjustment to suitable for all brushless motors
- Multiple protection features: Low voltage cut-off protection / Over-heat protection / Throttle signal loss protection / Motor blacked

Posted in New Arrival Product | Tagged , 105T, 250W, 3300KV, 90A, Blue, Brushless, ESC, EZRUN, HOBBYWING, ME154, Motor, Sensored | Leave a comment

HOBBYWING EZRUN 105T 3300KV 250W Sensored Brushless Motor Black 90A ESC ME155 New Arrival

Posted on April 25, 2013 by HobbyHot.com

HOBBYWING EZRUN 105T 3300KV 250W Sensored Brushless Motor Black 90A ESC ME155 – New Arrival!

HOBBYWING EZRUN 105T 3300KV 250W Sensored Brushless Motor Black 90A ESC ME155
Available at www.hobbyhot.com – Promising RC Model Shop Hong Kong,China
Check our cheap and high quality RC Model

Posted in New Arrival Product | Tagged , 105T, 250W, 3300KV, 90A, Black, Brushless, ESC, EZRUN, HOBBYWING, ME155, Motor, Sensored | Leave a comment

HOBBYWING EZRUN WP SC8 Waterproof 120A Brushless ESC Speed Controller SL564 New Arrival

Posted on April 23, 2013 by HobbyHot.com

HOBBYWING EZRUN WP SC8 Waterproof 120A Brushless ESC Speed Controller SL564 – New Arrival!

HOBBYWING EZRUN WP SC8 Waterproof 120A Brushless ESC Speed Controller SL564
Available at www.hobbyhot.com – Promising RC Model Shop Hong Kong,China
Check our cheap and high quality RC Model

Specification
Model: EZRUN-WP-SC8
Dimension: 59.3mm(L) x 38.4mm(W) x 33.6mm(H)
Cont. / Burst Current: 120A / 760A
Resistance: 0.0004 ohm
Suitable Car:
1/10 SCT / Truggy / Buggy / Monster
1/8 SCT / Buggy (Includes TRAXXAS 1/10 Truggy and Buggy)
Suitable Motor: Sensorless Brushless Motors
Suitable Motor Turns:
2S Lipo: KV<=6000, 3S Lipo: KV<=4000, 4S Lipo: KV<=3000
Battery: 6-12 cells Ni-xx (NiMH / NiCd) or 2-4 cells (Li-Po)
BEC Output: 6V/3A (Switching mode built-in BEC)

Net Weight: 113g (with 12AWG 200mm *5 wires)

Features
Completely water-proof and dust-proof. The ESC works properly even under water.
(Please remove the cooling fan when running car in water, and after running, please make the ESC clean and then dry it to avoid the oxidation of copper connectors)

Excellent start-up, acceleration and linearity features, suitable for truggy (especially short course trucks) and buggy.

The built-in switching mode BEC of EZRUN-SC8 ESC has a powerful output to supply all electronic equipments even with 4S Lipo Input.

Integrated and compact design, very suitable for trucks (especially short course trucks) and buggies.

There is a mounting stand for installing the ESC on chassis easily and firmly.

Proportional ABS brake function with 5 steps of maximum brake force adjustment, 8 steps of drag-brake force adjustment and 4 steps of initial brake force adjustment. Also compatible with the mechanical disc-brake system.

Multiple protection features: Low voltage cut-off protection / Over-heat protection / Throttle signal loss protection / Motor blocked protection.

Easily program with the SET button of the ESC, and also compatible with Pocket-sized Program Card (Optional Equipment) and the advanced LCD Program Box (Optional Equipment).

Special program port for connecting to the LED Program Card or the LCD Program Box. User needn`t unplug the Rx lead from receiver when programming the ESC.

Posted in New Arrival Product | Tagged 120A, Brushless, Controller, ESC, EZRUN, HOBBYWING, SC8, SL564, Speed, Waterproof, WP | Leave a comment

EL Model 300A RC Brushed Motor Speed Controller ESC for RC Hobby Car Ship SE090 New Arrival

Posted on February 20, 2013 by HobbyHot.com

EL Model 300A RC Brushed Motor Speed Controller ESC for RC Hobby Car Ship SE090 – New Arrival!

EL Model 300A RC Brushed Motor Speed Controller ESC for RC Hobby Car Ship SE090
Available at www.hobbyhot.com – Promising RC Model Shop Hong Kong,China
Check our cheap and high quality RC Model

Introduction

The EL Model 300A ESC allows remote control of car electric motors from an RC System. When connected with motor, it is capable of supplying up to 300 Amps (forward) or 150Amps (backward) of continuous motor current. Its integrated Battery Eliminator Circuit (BEC) powers the receiver from the motor battery, with automatic cutoff of the motor power to preserve receiver power as the battery becomes depleted. It is small and powerful, which can be used for different type of car or ship.

Specifications
Dimensions: 34.1mm x 34.6mm x 24.8mm
PWM Frequency: 1.5 KHz
Working Voltage: 7.2 – 8.4V
BEC Current: 6V/3A
Internal Resistance: 0.0087m ohm
Brust Output Current: 300A (Forward), 150A (Backward)
Continuous Output Current: 90A (Forward), 45A (Backward)
Cable Type: 16 AWG (Battery & Motor)
Cable Length: 90mm (Battery & Motor), 110mm (Receiver)
Input Battery Types: NiCd/ Nimh battery
Recommend Model: RC Car / Ship

Features
Forward, reverse, and brake Function
Low-Voltage, Cut Electricity Protection Function

Package Included
1 x EL Model 300A ESC (with English Manual)

Posted in New Arrival Product | Tagged 300A, Brushed, Car, Controller, EL, ESC, for, Hobby, Model, Motor, RC, SE090, Ship, Speed | Leave a comment

HOBBYWING XERUN Competition RC Brushless Motor 150A ESC Speed Controller SL241 New Arrival

Posted on February 20, 2013 by HobbyHot.com

HOBBYWING XERUN Competition RC Brushless Motor 150A ESC Speed Controller SL241 – New Arrival!

HOBBYWING XERUN Competition RC Brushless Motor 150A ESC Speed Controller SL241
Available at www.hobbyhot.com – Promising RC Model Shop Hong Kong,China
Check our cheap and high quality RC Model

Specification
Model: XERUN-150A
Dimension: 58mm(L) x 46.5mm(W) x 35mm(H)
Cont. / Burst Current: 150A / 950A
Resistance: 0.0002 ohm
Suitable Motor: Sensored and sensorless brushless motors

=>4.5T, KV<=3000 (Works with 4S Li-Po), =>6T, KV<=2400 (Works with 6S Li-Po)
Battery: 6-18 cells NiMH or 2-6 cells Li-Po
BEC Output: 5.75V/3A Switch mode built-in BEC
Cooling Fan Working Voltage: 5V, max. 8V (The fan gets the power supply from the built-in BEC)
Suitable Model: 1/5, 1/8 on-road, off-road, monster, Super powerful applications

Features
Compatible with all sensorless brushless motors and most of sensored brushless motors such as LRP, SpeedPassion, Novak, Etc.

Seamlessly change to sensorless working mode when the sensor cable is broken.

Excellent start-up, acceleration and linearity features.

Built-in switch mode BEC has a powerful output to supply all the electronic equipments.

Firmware can be updated through an USB adapter on the advanced LCD Program Box (Optional equipment).

User programmable. Easily programmed with the "SET" button on the ESC and also compatible with the digital LEDs Program Card and the advanced professional LCD Program Box.

3 running modes (Forward mode, Forward/Reverse mode, Rock Crawler mode).

4 steps of maximum reverse force adjustment.

Proportional ABS brake function with 4 steps of maximum brake force adjustment, 8 steps of drag-brake force adjustment and 4 steps of initial brake force adjustment.

9 start modes (Also called "Punch") from "very soft (Level 1)" to "very aggressive (Level 9)".

8 steps of timing adjustment to suitable for all brushless motors.

Multiple protection features: Low voltage cut-off protection / Over-heat protection / Throttle signal loss protection / Motor blocked protection.

Splash proof and dustproof.

Posted in New Arrival Product | Tagged 150A, Brushless, Competition, Controller, ESC, HOBBYWING, Motor, RC, SL241, Speed, XERUN | Leave a comment

New Product Arrival and Announcement – HobbyHot.com
